Shuttle Slim PC DH670V2 , S1700, 2x HDMI, 2x DP , 2x 2.5G LAN, 2x COM, 8x USB, 1x 2.5", 2x M.2, 24/7 permanent operation, incl. VESA
Varenummer: DH670V2EAN: 0887993005942
Specifikationer
Beskrivelse
Processor | |
Built-in processor | No |
Processor manufacturer | Intel |
Memory | |
Memory slots type | SO-DIMM |
Number of memory slots | 2 |
Maximum internal memory | 64 GB |
Supported memory clock speeds | 2133,2400,2666,2933,3200 MHz |
Supported memory types | DDR4-SDRAM |
Memory channels | Dual-channel |
Memory voltage | 1.2 V |
Non-ECC | Yes |
Storage | |
Supported storage drive types | HDD & SSD |
Storage drive sizes supported | 2.5,M.2 |
Storage drive interface | PCI Express, Serial ATA III |
NVMe | Yes |
Number of storage drives supported | 2 |
Graphics | |
On-board graphics card | Yes |
Graphics card family | Intel |
Audio | |
Built-in speaker(s) | No |
Network | |
Ethernet LAN | Yes |
Wi-Fi | No |
Ports & interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
HDMI ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
HDMI version | 2.0b |
DisplayPorts quantity | 2 |
DisplayPort version | 1.4 |
Microphone in | Yes |
Headphone outputs | 1 |
Serial ports quantity | 2 |
DC-in jack | Yes |
Design | |
Chassis type | 1.35L sized PC |
Product colour | Black |
Cooling type | Active |
Product type | Mini PC barebone |
LED indicators | HDD, Power |
Housing material | Metal |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
VESA mounting | Yes |
Panel mounting interface | 100 x 75 mm |
Safety | ETL, CB, BSMI |
Performance | |
Motherboard chipset | Intel H670 |
Processor socket | LGA 1700 |
Number of processors supported | 1 |
BIOS type | AMI |
Trusted Platform Module (TPM) | Yes |
Trusted Platform Module (TPM) version | 2.0 |
Windows operating systems supported | Windows 10, Windows 11 |
Linux operating systems supported | Yes |
Operating system installed | No |
Technical details | |
Sustainability compliance | Yes |
Sustainability certificates | BSMI, CB, CE, ENERGY STAR, ETL, ErP, Federal Communications Commission (FCC), RoHS |
Logistics data | |
Harmonized System (HS) code | 84733080 |
Power | |
Power supply type | External AC adapter |
Power supply | 120 W |
Number of power supply units | 1 |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
AC adapter output voltage | 19 V |
AC adapter output current | 6.32 A |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions | |
Width | 190 mm |
Depth | 165 mm |
Height | 43 mm |
Weight | 1.3 kg |
Package weight | 2.1 kg |
Packaging content | |
Power cord included | Yes |
AC adapter included | Yes |
Quick start guide | Yes |
Drivers included | Yes |
